Minimum system requirements
• Cable or DSL-modem with an Ethernet port
• A computer running Windows XP SP2, 2000 SP4 or Mac OS X (v10.4/v10.3) or Linux with installed Ethernet-adapter
• Internet Explorer 6 or Firefox 1.5 or higher
Standards
• IEEE 802.11b/g/n
• IEEE 802.3, 802.3u
WAN interfaces
• 1-port 10/100BASE-TX Ethernet
• Supports DSL and cable modem
LAN interfaces
• 4-port 10/100BASE-TX Ethernet
• All ports support auto MDI / MDIX cross
• All ports support flow control, 802.3x (full duplex) and back pressure (half duplex)
Antenna
• 2 fixed dipole antennas
Safety
• WEP 64/128-bit data encryption (user-selectable)
• Wi-Fi Protected Access (WPA/WPA2)
• WPS (Wi-Fi Protected Setup)
• Two SSID
Mximum speed of the Internet
(For hardware revision K1/K2)
• Static IP: 94.2 Mb / s
• Dynamic IP: 94.2 Mb / s
• PPTP: 85.6 Mb / s
• L2TP: 87.3 Mb / s
• PPPOE: 93.1 Mb / s
Wireless speeds
• 802.11b: 11, 5.5, 2 and 1 Mbit / s
• 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbit / s
• 802.11n: up to 300 Mbit / s
Transmitter output power
• 802.11b
17 dBm at 11, 5.5, 2 and 1 Mbit / s
• 802.11g
14 dBm at 54 Mbit / s
14 dBm at 48 Mbit / s
15 dBm at 36 Mbit / s
16 dBm at 24,18,12,9,6 Mbit / s
• 802.11n
13dBm at MCS0 ~ MCS15
Receiver sensitivity
• 802.11b
-85dBm at 11 Mbit / s
-86dBm at 5.5 Mbit / s
-87dBm at 2 Mb / s
-88dBm at 1 Mb / s
• 802.11g
-71 DBm at 54 Mbit / s
-72 DBm at 48 Mbit / s
-74 DBm at 36 Mbit / s
-75 DBm at 24 Mbit / s
-78 DBm at 18 Mbit / s
-82 DBm at 12 Mbit / s
-86 DBm at 9 Mbit / s
-88 DBm at 6 Mbit / s
• 802.11n (HT20)
-86 DBm at MCS0
-84 DBm at MCS1
-80 DBm at MCS2
-77 DBm at MCS3
-75 DBm at MCS4
-72 DBm at MCS5
-71 DBm at MCS6
-69 DBm at MCS7
• 802.11n (HT40)
-82 DBm at MCS0
-80 DBm at MCS1
-77 DBm at MCS2
-73 DBm at MCS3
-72 DBm at MCS4
-68 DBm at MCS5
-66 DBm at MCS6
-65 DBm at MCS7
Frequency band
• 2.4 to 2.462 GHz
Firewall security
• Network Address Translation (NAT)
• Stateful Packet Inspection (SPI)
• MAC-address filtering
• URL Content Filtering
Device control
• Managing Web-based interface using the browser Internet Explorer v6 or higher, or Firefox 1.5 or higher
Indicators
• Power
• Status
• Internet
• WLAN
• LAN (1 to 4)
